Product Information
Description:
SaltDogg® PRO4000CH Series Poly Hopper Spreaders with Conveyor Chain
Buyers Products SaltDogg PRO4000CH Series Poly Hopper Spreaders are a powerful spreader designed for commercial and municipal use. The spreader works with dump trucks and flatbeds with a minimum 17,500 GVW (gross vehicle weight). The 4 cubic yard spreader handles bulk salt, sand, or a 50/50 salt/sand mix. Its electric-powered design means quieter operation that doesn't require refueling or engine servicing, giving you more time on the road. The hydraulic version provides the extra power needed for municipal applications.
A PRO Series spreader is an investment made to last. The double-wall, lighter weight, all-poly hopper won't rust or dent. A simple cleaning makes it look like new. The spreader is supported by a corrosion-resistant stainless steel frame. An inverted V eases start up and works with the included 400 lb vibrator to break up clumps and keep material flowing.
The all steel 14-1/2 in. pintle chain conveyor with 1/4 in. bars, driven by a 3/4 HP, 12V gear motor or 3.17 CI hydraulic motor, feeds material at a smooth, steady pace. An 18 in. polymer spinner, powered by an independent 1/2 HP, 12V motor or 3.17 CI hydraulic motor, casts material 5-30 ft. The adjustable chute has an open trough and stainless steel spinner shield. The spinner assembly is easily removable for cleaning and storage.
Intuitive in-cab controls for the electric version let you independently manage conveyor and spinner speeds and turn the vibrator on and off with the flick of a switch. The spreader also comes standard with two steel top screens and a vinyl tarp with tie down kit.
The PRO4000CH Series is backed with a 2 year warranty.
A powerful spreader for commercial and municipal use.
Features:
- Works with dump trucks and flatbeds with minimum 17,500 lb GVW (gross vehicle weight).
- Durable 4 cubic yard poly hopper with stainless steel frame and trough.
- 12V DC-powered electric or hydraulic drive with independent conveyor and spinner motors.
- Handles bulk salt, sand, or a 50/50 sand/salt mix.
- In-cab control of independent auger and spinner speeds, with vibrator control electric version only.
- 18 in. spinner broadcasts material up to 30 ft.
- A high flow 14-1/2 inch conveyor chain keeps the material moving to the spinner.
- Included 400 lb vibrator keeps material from clumping and getting stuck.
- Top screens, inverted V, and tie downs included
- Backed with a 2 year warranty.
- Made in the USA.
- Industrial Parking Lots
- City Roadways
- Commercial Properties
- Apartment Complexes
Technical Details
- Mfg #
- PRO4000HCH
- SKU
- PRO4000HCH
- UPC
- 724920238557
- NMFC #
- 130355SUB5
- Feed Mechanism2
- 14 1/2 in. Pintle Chain with 1/4in. Bars
- Gearbox Ratio
- 20:1
- Spreading Width Range
- 5 to 30 feet
- Spinner Diameter
- 18.00 inch
- Spinner Material
- Polyurethane
- Chute
- Adjustable Height w/Side Swing
- Controller Type
- High Current Variable Speed
- Chute Primary Material
- Polyethylene
- Vibrator Force
- 450 pounds
- Vibrator Included?
- Yes
- Number of Motors
- 2
- Trough Material
- 304 Stainless Steel
- Feed Mechanism
- Conveyor Chain
- Top Screen
- Yes
- Works with Bagged #1 Rock Salt
- Yes
- Works with Bulk Sand
- Yes
- Works with Salt / Sand Mix
- Yes
- Works with Bulk Salt
- Yes
- Frame Base Width
- 56.40 inch
- Hopper Length (in.)
- 99.50 inch
- Hopper Width (in.)
- 74.00 inch
- Capacity
- 4.00 cubicyards
- Overall Width (at top)
- 74.00 inch
- Drive Type
- Electric
- Overall Length
- 114.80 inch
- Hopper Material
- Polyethylene
- Hopper Color
- Black
- Overall Height (in.)
- 43.50 inch
