SnowDogg® EX90II - 108" Snow Plow with RapidLink™ Attachment System

In order to add this product to your cart, configure a kit for your specific vehicle.

$6,529.00

Product Information

Description:

SnowDogg® EXII Snow Plow with RapidLink™ - 108" Blade with RapidLink™ Attachment System Complete Plow Package

Buyers Products SnowDogg EXII Snow Plow is an extreme duty straight blade plow for 3/4 ton+ pickups. Punch through heavy, wet snow with ease.

3/4 Ton with Plow Prep and 1+ Ton Trucks

Low Maintenance Blade

The corrosion resistant 304 stainless steel moldboard never needs paint. A robust frame spreads impact across the blade to reduce wear on vital components.

  • Full-length 2 in. cross tube
  • Heavy duty bottom channel
  • Nine 1/4 in. laser-cut steel ribs
  • 1/2 in. cutting edge
Quick and Easy Attachment

Mount and dismount in one minute or less with the new RapidLink™ Attachment System.

  • Center-mounted drop foot props up your plow on any surface with the pull of a handle
  • Hydraulically powered Jack Switch™ adjusts your plow's mounting height on the fly so it's easy to line up with your vehicle
  • Connects to your truck with a single driver side foot pedal
Clean, Even Scrape

The tubular steel Floating A-Frame features a sliding-pin connection, so the plow contours the ground for a clean, efficient scrape. Outstanding performance at any mounting height.

Smooth Full Trip Action

Four stress-optimized trip springs protect your equipment from hidden curbs and obstacles. Heavy duty shocks cushion the trip, providing a smooth ride for plow and driver alike.

Components You Can Rely On

From the municipal style chain lift to the fully enclosed hydraulic power unit, SnowDogg plows are built to endure whatever winter throws at you.

  • Powerful 2 in. lift cylinders
  • Over-sized 1-1/2 in. angle cylinders
  • Fully enclosed 2 HP hydraulic power unit
  • SAE standard cartridge valves and hefty 3/8 in. rubber hoses
  • Central hydraulic-operated life frame available
Included Accessories

Intuitive in-cab controls are simple to use even with gloves on. The backlit, one-handed controller puts all plows functions in the palm of your hand.

Other standard accessories:

  • Contoured poly snow deflector
  • Cast shoes
  • Wire reinforced blade guides
Ultra Bright LED Light Option

SnowDogg Illuminator™ LED Headlights are brighter and longer lasting than traditional halogens. Active Defrosting Technology™ keeps the Illuminators ice-free even in the biting cold - a central heat source defrosts the entire lens evenly, preventing the streaking or banding that's common with other LED plow lights.

SnowDogg HX High Intensity Halogens are also available.

Features:

  • Popular for: Ford® F-250
  • Chevy® Silverado 2500
  • RAM® 2500

Technical Details

Mfg #
EX90IIR
SKU
EX90IIR
NMFC #
130195SUB2
Weight
805 lbs.
Dimensions
108 × 34 × 10 inches
Electrical
Headlamp Rated Replaceable Micro-ISO Relays
Moldboard Material
304 Stainless Steel
Ribs
9
Lift Cylinder
2 x 6 inch
Angle Cylinders
1 1/2 x 12 inch
Snow Deflector
Contoured Poly
Plow Type
Straight Blade
Trip Springs
4
Blade Height
31 inch
Cutting Edge
1/2 x 6 inch
Plow Shoes
Standard
Mounting System
RapidLink™ Attachment System
Moldboard Thickness
12 Gauge
Lights
Dual Halogen Bulbs or Illuminator™ Heated LEDs
Stand
Drop Leg
Harnesses
Separate Light and Hydraulic 4GA Power Wires
Angled Blade Width
93.5 inch
Trip Style
Full Trip
Blade Width
108 inch
