Product Information
Description:
50 Gallon Side Mount Steel Reservoir
The Side Mount Steel Reservoir from Buyers Products is built of tough 13 Ga steel and is designed to install on the side of your truck.
The reservoir is fully baffled to control fluid movement and keep things cool. It features a black powder-coated finish for enhanced corrosion resistance.
The tank has a 2 in. NPT return port/drain on its bottom.
Each unit includes a sight level and temperature gauge and a quarter turn filler breather unit. Mounting brackets are sold separately (see "Accessories" below).
Please Note: Mounting Kit #SMS005BK is required to mount tank or warranty is void.
Features durable 13 Ga steel construction.
Features:
- Tough, durable 13 Ga steel construction.
- Fully baffled to keep oil cool and moving correctly.
- Includes level/temperature sight gauge.
- Truck and Trailer Hydraulic Systems
- Semis/OTR Trucks
- Service Trucks
Technical Details
- Mfg #
- SMS50SQ
- SKU
- SMS50SQ
- UPC
- 724920075428
- NMFC #
- 181390
- Weight
- 115 lbs.
- Dimensions
- 25 × 27 × 27 inches
- Suction Port Size
- 2 NPT
- Temperature Gauge (y/n)
- Yes
- Included Valve (y/n)
- No
- Oil Level Gauge (y/n)
- Yes
- Mount Position
- Upright
- Reservoir Shape
- Rectangle
- Integral Level Gauge (y/n)
- Yes
- Integral Brackets (y/n)
- Yes
- Height
- 23 inch
- Width
- 23 inch
- Depth
- 25 inch
- Color
- Black
- Usable Capacity
- 50 gallons
- Capacity
- 50 gallons
- Material Gauge
- 13
- Finish
- Powder-Coat
- Material
- Carbon Steel
- Hardware and Brackets Included (y/n)
- No
