Expressway Plow - 12 Foot Carbon Steel Blade, Trip Edge, Swivel, 3 Inch Cylinders
Product Information
Description:
SnowDogg® Expressway Municipal Snow Plow - Carbon Steel Blade with Trip Edge
Buyers Products SnowDogg® Expressway Full Trip Municipal Snow Plow with Carbon Steel Blade is a high speed interstate plow. The Expressway's massive flared blade stands 40 in. high in the middle and 55 to 56 in. at either end. It's built with sturdy 7 Ga steel with eight 1/2 in. reinforcing ribs and finished with a corrosion-resistant orange Tuff Kote™ powder coat. The roll-formed design creates an integral deflector that improves operator visibility by reducing drift. It also throws snow substantially farther than a traditional straight blade. The plow's trip edge design helps protect your equipment from unseen obstacles without dumping the load of snow you're pushing.
Fortified components give the Expressway the power needed to plow large amounts of heavy snow at high speeds. The tubular steel push frame spans the width of the moldboard ribs to spread impact force and reduce wear, and the sector features sturdy 3/4 in. angular construction. Double acting chrome angle cylinders provide powerful hydraulic reversing. A heavy duty level chain lift keeps the plow parallel to the ground regardless of terrain. All steel components have a corrosion-resistant black powder-coated finish.
A powerful municipal plow designed for high speed interstate use.
Features:
- Designed for high speed interstate plowing.
- Flared moldboard stands 40 in. high in the middle and 55 to 56 in. (depending on model) at either end.
- Integral roll-formed deflector reduces drift to improve driver visibility and throws snow farther than a traditional straight blade.
- Corrosion resistant Tuff Kote™ orange powder-coated finish on the blade and a black powder-coated finish on the frame.
- Trip edge design helps protect equipment from unseen curbs and other obstacles.
- Tubular steel push frame spans the width of the moldboard's ribs for exceptional strength and to spread impact force.
- Sturdy 3/4 in. angular construction on the sector provides durability where it's needed most.
- Made in the USA.
Technical Details
- Mfg #
- 1664410200
- SKU
- 1664410200
- UPC
- 724920170611
- NMFC #
- 130195SUB2
- Angle Cylinder Action
- Double Acting
- Angle Cylinder Dimensions
- 3 x 2 x 12 inch
- Trip Style
- Trip Edge
- Number of Ribs
- 8
- Blade Height
- 40/56 inch
- Cutting Edge Material
- 1080 Steel
- Rib Thickness
- 0.50 inch
- Attachment Style
- Swivel
- Tubing Material
- Carbon Steel
- Number of Trip Springs
- 5
- Trip Spring Syle
- Torsion
- King Pin Diameter
- 2.00 inch
- Material
- Carbon Steel
- Finish
- Powder Coat with Primer
- Push Frame Tubing Dimensions
- 4 x 3/8 inch
- Tubing Diameter
- 3 x 1/2 inch
- Color
- Orange
- Rib Material
- Carbon Steel
- Cutting Edge Dimensions
- 8 x 5/8 inch
- Blade Width
- 144 inch
