Diamond Tread Aluminum Straight Side Backpack Truck Tool Box - Compression Latch
Product Information
Description:
Diamond Tread Aluminum Straight Side Backpack Truck Tool Box Series with Flat Floor
Buyers Products Diamond Tread Aluminum Straight Side Backpack Truck Box provides convenient and spacious storage behind the cab. Two fixed shelves give you a multitude of options for organizing your tools and equipment. The tool box features a rugged .100 in thick aluminum body with full-height doors and dual die-cast compression latches. Stainless steel continuous hinges provide years of reliable strength.
The box is ideal for use on cab-over trucks. It allows clearance for frame-mounted battery boxes and tanks. Installation is easy with built-in frame mounting rails. Rubber D-bulb sealed doors, and a built-in rain channel helps protect your tools and equipment from weather and theft. A spring-cushioned mounting kit is included for easy installation. Failure to use supplied mounting kit may void the warranty.
Provides convenient and spacious storage. Ideal for flatbeds, stake bodies, dump trucks, and utility bodies.
Features:
- Flat base above floor, ideal for cab-over trucks.
- Provides clearance for frame-mounted battery boxes and tanks.
- Two stationary shelves plus floor storage provide ample room.
- Locking die cast compression latches help keep your equipment secure.
- Automotive style rubber D-bulb sealed doors and a built in rain gutter protect against weather and grime.
- Two full-height doors with stainless steel, 1/4 in. pin continuous hidden hinges.
- Save time on installation with built-in frame mounting rails and two folding drivers side J-hooks.
- Must be installed using included spring-cushioned mounting kit.
- Made in the USA.
- Cab-Over Trucks
- Dump Bodies
Technical Details
- Mfg #
- BP964824
- SKU
- BP964824
- UPC
- 724920178389
- NMFC #
- 29900SUB3
- Weight
- 369 lbs.
- Dimensions
- 100 × 36 × 53 inches
- Number of Doors
- 2
- Depth
- 24.0 inch
- Height
- 48.0 inch
- Width
- 96.0 inch
- Door Opening Height
- 42.0 inch
- Door Opening Width
- 17.8 inch
- Door Material
- Aluminum
- Door Finish
- Diamond Tread
- Box Material
- Aluminum
- Door Gauge
- 0.100\"
- Box Finish
- Diamond Tread
- Box Gauge
- 0.100\"
- Gasket Type
- Automotive Bulb Seal
- Box Thickness
- Aluminum - 0.100\"
- Latch Style
- Die Cast Compression Latch
- Lock Included (y/n)
- Yes
- Shelf
- True
- Pro Series
- False
- Hinge Style
- Stainless Steel Hinge
- Rain Gutter
- True
